CNC Semi Production Lathe

CNC Semi Production Lathe

Product Code CNC-SP-0001
  • Industrial-grade Servo motor drives
  • Fanuc / Siemens-compatible controller
  • Complete CAD-CAM software included
  • Onsite installation & faculty training
  • Bulk tender supply & worldwide export
Get Bulk Tender Quote
Send Enquiry
Tell A Friend Print Datasheet Save
Need help with bulk procurement?

Talk to our tender team — BOQ & technical bid documents in 24 hours.

+91-9896600003 · sales@naugracnc.com
CNC Semi Production Lathe

This CNC Lathe is perfectly suitable to be used for light production purpose.

This is the ideal product for educational institutes which are looking to impart industrial training to their students as well as doing some light production activity on the same machine.

HPL series Turning machines are equipped with production turrets. LM Guides and metallic bellows covering the are also provided.

Technical Specifications:

Bed Type Flat / 45 Degrees Slant
Chuck Size 125 mm (Dia)
Chuck Type Hydraulic/ Manual
Maximum Turning Dia / Length 80 mm / 250 mm
Center Height 100 mm
Swing over Cross Slide 100 mm
Swing Over Bed 200 mm
Distance between Centre 320 mm
Controller Siemens / Fanuc
Positioning 0.010 mm
Repeatability +- 0.005 mm
Resolution 0.001 mm
Spindle Motor AC Servo
Spindle Motor Capacity 3.7 KW / 5 HP
Spindle RPM 100 to 4000 RPM with VFD
Spindle Nose Taper A 2-3 / A 2-5
Axis Motor and Drive Servo Motor with Servo Drives
X Axis Travel 100 mm
Z Axis Travel 300 mm
Feed Rate 0 to 10,000 mm/min
Rapid Travel 10,000 mm/min / 20,000 mm/min
Turret Type Automatic - Servo Type
Number of Stations 4 / 8
Tool Cross Section 16 mm x 16 mm
Boring Bar Size 16 mm
Tailstock Base Stroke 200 mm
Tailstock Quill Stroke 1000 mm
Tailstock Actuation Hydraulic/ Manual
Lubrication Automatic
Coolant Automatic
FMS Compatibility Provided
Dimension in mm 1500 x 1200 x 1700 mm
Power Supply 415V, +-2% 50 Cycles, 3 Phase

Every Naugra CNC CNC Semi Production Lathe is shipped with the following items, factory-tested and ready for installation:

Complete CNC Semi Production Lathe, factory tested
Servo motor drives with industrial-grade controllers
Fanuc / Siemens-compatible CNC control system
CAD-CAM software (BobCAD / CutViewer / NC Guide)
Onsite installation & commissioning by Naugra engineers
Faculty & lab-technician training programme
Syllabus-aligned lab manual and exercise sheets
Standard tooling kit and accessories
1 year onsite warranty
