Model

CNC Controller

Windows Based Software

CNC Software

Mach3

Axis Motor & Drive

AC Servo (1.3 Nm)

Spindle Motor

1 HP with VFD (3PH)

Spindle Motor Speed

100 to 3000 rpm

Stabilizer

3 KVA

Lubrication System

Automatic (Motorized)

Max. Depth Of Cut

1 mm Possible

Table Size

200 X 600 mm

Axis Travel X , Y & Z Axis

275 mm, 150 mm, 250 mm

Axis Control

3 Axis

Axis Plane

XY, XZ & YZ

T Slot

12 mm

Repeatability

±0.005mm

Rapid Feed  Rate X

1000 mm/Min

Rapid Feed  Rate Y

1000 mm/Min

Rapid Feed  Rate Z

1000 mm/Min

Ball Screw (HIWIN)

X Ø 20X5,Y Ø 20X5 & Z  Ø25X5mm

Max. Rapid Feed

4000 mm/Min

Minimum Increment

0.001 mm

Slide

Cross

Collet Holder

R8

Positional Accuracy

±0.005mm

Repeatability

±0.005mm

Table Load Capacity

100 Kg

Machine Dimensions

1200 X 1200 X  1600 mm.

Machine Weight

Approx.700 kg
