Model

Trainer CNC Lathe.

CNC Controller

Sinumerik 808 D

Axis Motor & Drive

AC Servo (1.3 Nm & 1.3 Nm)

Spindle Motor

2 HP with VFD/1.7Kw

Max Depth of cut

2 mm possible.

Spindle Motor Speed

100 to 3000 rpm

Lubrication System

Automatic (Motorized)

Swing Over Bed

250 mm

Swing Over Carriage

100 mm

Centre Height

200 mm

Max. Machining Diameter

60 mm

Max Turning Length

150 mm

Max. Longitudinal Travel

300 mm

Spindle inside Taper

MT-3

Spindle Type

  Regular

Spindle Bore

Dia 38 mm

Standard Cutting Tool Size

20 X 20

Input System

Metric / Inch

Chuck Size

Dia 110 mm

Rapid Feed Rate Axis

1000 mm/Min.

Max. Rapid Feed

4000 mm/Min.

Accuracy

0.005μ

Ball Screw

HIWIN.

Horizontal Tool Changer

4 Station
