Servo is a servo motor based CNC Trainer machine. We have
successfully implemented Servo technology in our Trainer machines. Now
it is possible to provide hands on experience to students to most of the
machine tool industry norms. Rapid travel of 10,000 mm/min and Fanuc /
Siemens emulated keyboard imparts necessary industrial grade machine
experience to students.
Complete independence from computer (No
I/O card used) prevents this machine from any issues related with
electrical supply (Noise and Spikes). Down time of PLC based machines is
90% less as compared to other computer (I/O Card) based machines.
Also,
PLC allows machines to be operated remotely. Hence problem
detection and eventual solution can be attained within minutes.
Specifications:
| Bed Type |
Flat / 45 Degrees Slant |
| Keyboard Type |
Fanuc Emulated / Manual |
| Chuck Size |
150 mm (Dia) |
| Chuck Type |
Hydraulic |
| Maximum Turning Diameter |
100 mm |
| Maximum Turning Length |
250 mm |
| Center Height |
150 mm |
| Swing over Cross Slide |
125 mm |
| Swing Over Bed |
300 mm |
| Distance between Centre |
320 mm |
| Controller |
Hytech with CutViewer-United Kingdom |
| Control System |
PLC Based Control System |
| Operating Software |
CutViewer - United Kingdom |
| Positioning |
0.005 mm |
| Repeatability |
+/- 0.005 mm |
| Resolution |
0.001 mm |
| Spindle Motor |
AC Servo |
| Spindle Motor Capacity |
3.7 KW / 5 HP |
| Spindle RPM |
100 to 4000 RPM with VFD |
| Spindle Nose Taper |
A 2-5 |
| Axis Motor and Drive |
Servo Motor with Servo Drives
(Mitsubishi / Siemens) |
| X Axis Travel |
100 mm |
| Z Axis Travel |
300 mm |
| Ball Screw X / Z |
Ø25 x 5 - C3 Class |
| Programmable Feed Rate |
0 to 10,000 mm/min |
| Rapid Travel |
10,000 mm/min |
| Turret Type |
Automatic |
| Number of Stations |
4 / 8 |
| Tool Cross Section |
12 mm x 12 mm |
| Boring Bar Size |
16 mm |
| Tailstock Base Stroke |
170 mm |
| Tailstock Actuation |
Hydraulic/ Manual |
| Lubrication |
Automatic |
| Coolant |
Automatic |
| FMS Compatibility |
Provided |
| Dimension in mm |
1520 x 800 x 1200 mm |
| Power Supply |
415V, +-2% 50 Cycles, 3 Phase |
Every Naugra CNC CNC Lathe Trainer is shipped with the following items, factory-tested and ready for installation:
Complete CNC Lathe Trainer, factory tested
Servo motor drives with industrial-grade controllers
Fanuc / Siemens-compatible CNC control system
CAD-CAM software (BobCAD / CutViewer / NC Guide)
Onsite installation & commissioning by Naugra engineers
Faculty & lab-technician training programme
Syllabus-aligned lab manual and exercise sheets
Standard tooling kit and accessories
BOQ & Technical Bid Documents
Complete bill-of-quantities, technical specification sheets and OEM authorisation letters delivered within 24 hours of your tender enquiry.
Direct from Manufacturer
No middlemen, no markup. Direct factory pricing for engineering colleges, ITIs, polytechnics and government skill-development centres.
30-45 Day Delivery
Bulk-order delivery within 30-45 days for India and 45-90 days for export shipments — full packing, shipping and clearance handled.
Installation & Training Included
Every order includes onsite installation, commissioning, faculty training and lab-staff handover — no extra cost.
