Code: CNC-MT-0001
CNC Mill Trainer.
This is our highest selling model (Among CNC Milling Trainer
Machines) in Indian subcontinent. Rigid design and PLC based technology
gives this machine a technological advantage over its competitors.
Complete independence from computer (No I/O card used) prevents this machine from any issues related with electrical supply (Noise and Spikes). Down time of PLC based machines is 90% less as compared to other computer (I/O Card) based machines.
Also, machines to be
operated remotely. Hence problem detection and eventual solution can be
attained within minutes.
Specifications:
| Axis Motor and Drive | Stepper Motor with Stepper Drives |
| X Axis | 225 mm |
| Y Axis | 150mm |
| Z Axis | 150 mm |
| 4th Axis Provision (Optional) | Not Provided |
| Table top to Spindle Nose distance | 70 - 290 mm |
| Spindle to column distance | 270 mm |
| Feed Rate | 0 to 1,000 mm/min |
| Rapid Travel | 1,000 mm/min |
| Table Size | 560 x 220 mm |
| T Slot | 3 x 10 x 50 |
| Load on Table | 120 Kg |
| Spindle Motor Capacity | 1.5 HP |
| Spindle Nose Taper | ISO 30 / BT 30 |
| Spindle RPM | 100 to 3000 RPM |
| Controller | CutViewer-United Kingdom |
| Control System | PLC Based Control System |
| Operating Software | CutViewer - United Kingdom |
| Positioning | 0.010 mm |
| Repeatability | +- 0.015 mm |
| Resolution | 0.010 mm |
| 4th Axis Resolution (Optional) | Not Provided |
| Tool Changer | Automatic / Manual Quick Tool Change |
| No. of Tools | 8 |
| Maximum Tool Length | 40 mm |
| Maximum Tool Dia. | 16 mm |
| Actuation | Hydraulic (Compressor not required) |
| Interpolation | Linear / Circular / Parabolic |
| Pocket & Helical Milling | Provided with standard codes |
| Dimension in mm | 1150 x 1000 x 1750 mm |
